20PCS CMK SERIES PUSH IN QUICK CONNECTOR terminal block 32A 2 3 4 5 circuits

20PCS CMK SERIES PUSH IN QUICK CONNECTOR terminal block 32A 2 3 4 5 circuits

$3.28 USD
$3.28 USD
促销 售罄
                      20PCS NEW

                   PUSH IN QUICK CONNECTOR

           Terminal Block

Flexible wire：0.08-1.5mm2

Rigid wire:0.2-4mm2




Material of connectors shell: Polyamide Pa66
Material of actuating levers: Polyamide Pa66
Material of conductive parts: Thinned copper
Material of contact springs: AISI 301 stainless steel
Rated voltage(V): 415V AC
Rated current(A): 32A
Connection capacity: 0.08-4mm2
Type of electric connection: Equipotential
Working temperature: -20  to +85
Strip length: 11mm/0.43 Inch
